介紹釀酒設備涼茬機電機使用前的檢查方法

發布于:2021-04-25 16:06:09  來源:http://gzxiangge.com

全自動涼茬機是由機架、風機、傳送帶、打料棍、下料裝置、以及出料管組成的,該機將攤晾、加漿、加曲、攪拌、卸料等工藝一次性加工完成的,與傳統工藝相比,大大的降低了勞動的強度,實現自動化生產。全自動涼茬機提高了冷卻效果、同時降低了功耗,還了以前設備自積堵塞現象,是理想的冷散設備。
The automatic stubble cooling machine is composed of frame, fan, conveyor belt, beating stick, blanking device and discharge pipe. The machine processes the spreading and drying, adding pulp, adding koji, mixing and discharging at one time. Compared with the traditional process, it greatly reduces the labor intensity and realizes automatic production. The automatic stubble cooler improves the cooling effect, reduces the power consumption, and solves the self accumulation and blockage of the previous equipment. It is an ideal cooling equipment.
全自動涼茬機的組成部分
Components of automatic stubble cooling machine
1.主要由機架、風機、傳送帶依次連接于傳送帶上的攪籠、打料棍、翻料棍、下料裝置、出料管組成.
1. It is mainly composed of frame, fan, conveyor belt, mixing cage, beating stick, turning stick, blanking device and discharge pipe connected to the conveyor belt in turn
2.風機固定在傳送帶側端的機架上并少設置為三臺,所述的下料裝置由下料斗和固接于下料斗下部的下料輥組成,所述的機架上設有高于傳送帶輸送線兩邊的擋板。
2. The fan is fixed on the frame at the side end of the conveyor belt and at least three fans are set. The blanking device is composed of a hopper and a blanking roller fixed at the lower part of the hopper, and the frame is provided with baffles higher than both sides of the conveyor line of the conveyor belt.
3.使用時,酒茬在傳送帶上通過,在打碎和攪拌的同時風機工作,酒糟涼茬機,迅速降溫,冷卻后的酒茬在下料裝置中與酒曲自動混合均勻。
3. When in use, the stubble passes through the conveyor belt, the fan works while crushing and stirring, and the distiller's grains cooling machine cools down quickly, and the cooled stubble is mixed with distiller's yeast automatically and evenly in the blanking device.
4.實用新型全自動涼茬機提高了冷卻效果、降低了功耗,了現有設備自積堵塞現象,并實現了酒茬和酒曲的自動混合。
4. The utility model automatic stubble cooling machine improves the cooling effect, reduces the power consumption, solves the self accumulation and blockage phenomenon of existing equipment, and realizes the automatic mixing of stubble and koji.
釀酒設備涼茬機電機使用前的檢查方法
Inspection method for motor of stubble cooler of liquor making equipment before use
1、用壓縮空氣或手動吹風機吹凈電動機內部灰塵、電刷粉末等,污垢雜物。
1. Use compressed air or manual blower to clean the dust and brush powder inside the motor to remove the dirt.
2、拆除與電動機連接的一切接線,用絕緣電阻表測量繞組對機座的絕緣電阻。若小于0.5MΩ時,應進行烘干處理,測量合格后再將拆除的接線恢復。
2. Remove all the wiring connected with the motor, and measure the insulation resistance of the winding to the base with an insulation resistance meter. If less than 0.5m Ω After the measurement is qualified, the removed wiring shall be restored.
3、檢查涼茬機換向器的表面是否光潔,如發現有機械損傷或火花灼痕應進行必要的處理。
3. Check whether the surface of the commutator of the stubble cooler is smooth and clean. If any mechanical damage or spark burn mark is found, necessary treatment shall be carried out.
4、檢查電刷是否嚴重?fù)p壞,刷架的壓力是否適當,刷架的位置是否位于標記的位置。
4. Check whether the brush is seriously damaged, whether the pressure of the brush holder is appropriate, and whether the position of the brush holder is in the marked position.
5、根據涼茬機電動機銘牌檢查直流電動機各繞組之間的接線方式是否正確,電動機額定電壓與電源電壓是否相符,涼茬機,電動機的起動設備是否符合要求,是否完好無損。
5. According to the motor name plate of the stubble cooler, check whether the wiring mode between the windings of the DC motor is correct, whether the rated voltage of the motor is consistent with the power supply voltage, whether the stubble cooler and the starting equipment of the motor meet the requirements, and whether they are intact.
