1、攤晾機全部采用304拉絲方管和304拉絲板焊接而成，強度高，外觀整齊美觀，不生銹，易保養擦拭；內部風室設計有直通排水口，鏈道、風室等可直接用水沖刷。
1. The spreading and airing machine is made of 304 wire drawing square tube and 304 wire drawing plate by welding, with high strength, neat and beautiful appearance, no rust, easy maintenance and wiping; the internal air chamber is designed with straight drainage outlet, and the chain channel and air chamber can be directly washed with water.
2、整機變頻調速控制，自動加曲速度無級調節，出料口加紅外溫度傳感器，自動控制凉糟溫度，根據溫度控制風機啟停個數及風量大小，達到凉糟降溫目的，并降耗。
2. The whole machine is controlled by frequency conversion and stepless adjustment of automatic warping speed. The outlet is equipped with infrared temperature sensor to automatically control the temperature of waste grains. According to the temperature, the number of fans and air volume are controlled to achieve the purpose of waste grains cooling and save energy.
3、主傳動采用國產減速機和一級大模數齒輪傳動，結構緊湊，輸出力矩大，不易損壞；涼糟鏈條運行速度變頻器控制，在0.5-2.6m/m范圍內無級調整，滿足凉糟機工藝要求；凉糟機出口安裝有溫度傳感器，實時測控出糟溫度并控制涼糟鏈條運行速度，保證攤晾效果；
3. The main drive adopts domestic reducer and one-stage large module gear transmission, which has compact structure, large output torque and is not easy to be damaged; the running speed of the cooling grain chain is controlled by frequency converter, which can be adjusted steplessly in the range of 0.5-2.6m/m to meet the technological requirements of the grain machine; the outlet of the grain machine is equipped with a temperature sensor, which can measure and control the temperature of the grain in real time and control the running speed of the cooling grain chain, so as to ensure the air spreading effect;
4、涼糟篩板用304不銹鋼沖制成型，節距100，寬度1220，篩孔采用長條孔，無飛邊毛刺，透氣性好；篩板底部滾輪支撐，料斗下料時篩板不變形；
4. The screen plate is made of 304 stainless steel, with a pitch of 100 and a width of 1220. The screen holes are long holes, without flash and burr, and have good air permeability;
5、采用三臺或四臺強力離心風機冷卻酒糟，風機均可變頻調速和工頻運行，根據出口溫度由電腦自動控制每臺風機的開停、變頻運行和工頻運行，配合兩套翻渣輥對酒糟翻動,既減少耗能，又可保證酒糟攤晾效果；每個風機獨立風室經優化設計，內部設計有專門結構，分層送風，保證篩板均勻受風冷卻；
5. Three or four powerful centrifugal fans are used to cool the distiller's grains. The fans can be operated with frequency conversion and power frequency. According to the outlet temperature, the computer can automatically control the start and stop, frequency conversion and power frequency operation of each fan, and cooperate with two sets of slag roller to turn the distiller's grains, It can reduce energy consumption and ensure the effect of distiller's grains spreading and airing;
6、按配套工藝要求設計的加曲機可自動加曲，帶稱重傳感器，自動調節電機頻率控制加曲配比，可精確控制加曲比例；酒糟加曲后經揚片機翻拌后落入料斗（或接糟池），保證加曲后的充分混合；
6. The koji adding machine designed according to the matching process requirements can automatically add koji, with a weighing sensor, automatically adjust the motor frequency, control the koji adding ratio, and accurately control the koji adding ratio; after koji adding, the distiller's grains fall into the hopper (or distiller's pool) after being stirred by the lifting machine to ensure the full mixing after koji adding;
小型全自動涼茬機
Small automatic stubble cooling machine
如何選擇涼茬機 釀酒涼茬機品種齊全 省時
How to choose the cooling stubble machine for liquor making
7、攤晾機自帶不銹鋼操作平臺，可隨時觀察機器工作情況并可隨時人工介入調整。
7. With stainless steel operating platform, the machine can be observed at any time and adjusted manually at any time.
8、攤晾機出口處設計有不銹鋼漿水噴淋管，方便酒糟攤晾后加漿水，將水管裝有流量計加漿水均勻、可控。
8. A stainless steel slurry spray pipe is designed at the outlet of the spreading and airing machine, which is convenient for adding slurry after the distiller's grains are spread and aired. The water pipe is equipped with a flowmeter, and the slurry is added evenly and controllable.
9、機器風室都設計有清理門，方便機器內部殘渣清掃。
9. The air chamber of the machine is designed with a cleaning door to facilitate the cleaning of residues inside the machine.
